HEIMAN S1-R | UL 217-Certified RF915 MHz Interlinked Smoke Detector

2026-04-27

Model: S1-R | Brand: heiman | Certification: ETL Listed to UL 217 (10th Edition), FCC/IC Compliant | Protocol: RF 915 MHz ISM Band | Application: Whole-Building fire safety & Multi-Unit Interconnection

Core Communication & IoT Advantages

The HEIMAN S1-R is engineered as a dedicated wireless interconnected smoke detector operating on the 915 MHz ISM band, a frequency specifically optimized for robust, low-interference fire alarm signaling across complex residential and commercial structures. Unlike Wi-Fi or Bluetooth-dependent devices, the S1-R operates independently of internet connectivity, ensuring uninterrupted alarm propagation even during network outages.

Hub-Free RF Interconnection: Utilizes a peer-to-peer 915 MHz radio protocol with forward-error correction and frequency hopping spread spectrum (FHSS) techniques. Up to 40 detectors can be grouped under one network, delivering synchronized alarming with <2 seconds latency across multiple floors and rooms.
Whole-Building Coverage & Deep Penetration: 915 MHz RF signals naturally penetrate drywall, concrete, and metal framing more effectively than 2.4 GHz or 5 GHz bands, making the S1-R ideal for multi-story homes, apartment complexes, and retrofitted properties without dedicated fire alarm cabling.
Source-Tracking Location Identification: Each S1-R unit transmits a cryptographically unique RF ID during alarm activation. Paired with the HEIMAN Smart App or compatible RF bridge, building managers receive precise, unit-level location alerts (e.g., "Unit S1-R-04 Triggered: 2nd Floor Kitchen"), enabling rapid emergency response.
Power & Network Resilience: Local RF interlinking requires zero cloud dependency for core alarm functions. Battery-backed RF modules maintain synchronization for 24+ months, with tamper supervision, low-battery reporting, and automatic re-pairing upon replacement.

Core Features & Authoritative Technical Validation

The S1-R integrates advanced photoelectric sensing with a compliance-driven nuisance alarm reduction architecture, specifically validated under the latest UL 217 standards to address real-world residential fire detection challenges.

UL 217 10th Edition Certified Compliance: Fully tested and ETL Listed to the 10th Revision of UL 217, which introduced rigorous performance benchmarks for cooking aerosol resistance, long-term sensitivity stability, and alarm consistency.
- Per UL 217 10th Ed., Section 45 (Nuisance Alarm Tests – Cooking Smoke & Steam), the S1-R is validated to distinguish between transient, low-density cooking vapors (e.g., burger grilling, toaster smoke, boiling steam) and life-threatening combustion events.
- Per Section 48 & 50 (Smoke Entry & Alarm Activation Requirements), the detector maintains a calibrated sensitivity threshold of ≤0.9 dB/m obscuration, ensuring rapid response to smoldering fires while filtering out non-hazardous particulate matter.
Intelligent Particle Analysis & Nuisance Filtering: The multi-path optical chamber pairs with firmware-based dispersion pattern recognition. The algorithm evaluates smoke density, entry velocity, and particulate size distribution in real-time, suppressing false triggers from high-temperature cooking while preserving sub-60-second activation for actual fires.
Photoelectric Optimization for Modern Combustion: Modern residential fires (upholstered furniture, synthetic materials) smolder longer and produce larger smoke particles. Photoelectric sensing is scientifically preferred for early detection of these fires, aligning with NFPA 72 guidance and municipal fire code updates.
Self-Diagnostic & Supervision Protocols: Continuous RF heartbeat monitoring, optical chamber drift compensation, and tamper detection ensure operational readiness. All fault states are logged and reported with timestamped clarity.

Technical Specifications

Application Scenarios & Installation Guidelines

The S1-R is purpose-designed for scalable, whole-building fire protection where wiring is impractical, retrofitting is required, or multi-unit synchronization is mandatory.

Ideal Deployment Environments:

Multi-family residential buildings & townhouses
Student housing, senior living facilities & co-living spaces
Short-term rental properties (Airbnb, VRBO) & boutique hotels
Large single-family homes requiring floor-to-floor alarm synchronization

Installation & Grouping Best Practices (NFPA 72 & UL 217 Aligned):

Placement Strategy: Mount on ceilings at room centers, ≥10 ft from cooking surfaces. Avoid corners, HVAC diffusers, bathrooms, and unheated attics. Wall mounting is permissible with top-edge 4–12 inches below ceiling.

RF Network Pairing: Host device-Press reset button with pin 3 times then long press within 2 seconds.

Sub device-Press reset button with pin 2 times then long press within 2 seconds

When it paired sucess,there will a beep in both device.

Interference Mitigation: Maintain ≥3 ft from large metal appliances, routers, or high-power RF emitters. 915 MHz naturally avoids Wi-Fi congestion zones.
Testing & Commissioning: Use the built-in test button to verify optical sensing, horn output, and RF interlink propagation. Confirm all grouped units trigger simultaneously and location alerts display correctly in the app/panel.
Maintenance Schedule: Test monthly via app or physical button. Clean optical chamber bi-annually with compressed air. Replace batteries when low-battery alert triggers.

Frequently Asked Questions (FAQ)

Q1: Why does the S1-R use 915 MHz RF instead of Wi-Fi or zigbee?
RF 915 MHz is a dedicated ISM band for industrial and safety applications. It offers superior wall penetration, operates independently of home internet, and provides deterministic, low-latency alarm propagation. This makes it more reliable than consumer Wi-Fi for life-safety interconnection.

Q2: How effectively does it prevent false alarms from cooking (e.g., hamburger smoke, steam)?
The S1-R’s firmware is calibrated per UL 217 10th Ed. Section 45, which mandates stringent cooking nuisance resistance testing. The algorithm analyzes particulate density and dispersion timing, ignoring transient cooking vapors while maintaining rapid response to actual combustion.

Q3: How does the location-specific alarm feature work?
S1-R unit contains private information code. When triggered, it broadcasts this across the synchronized network. Compatible controllers or the HEIMAN App instantly map the signal to a pre-assigned room/location, displaying precise origin data for emergency responders or property managers.

Q4: Can I mix S1-R units with other Heiman smoke detectors?
The S1-R uses a proprietary 915 MHz FHSS protocol optimized for UL 217 interlinking. For mixed environments, use protocol-specific gateways or deploy Heiman same RF networks per building zone.

Q5: What happens if the internet goes out during a fire?
Core interlinking, horn activation, and RF synchronization operate entirely offline. Cloud/App features (location logging, remote notifications) require Wi-Fi, but life-safety alarming remains 100% functional via local RF.
