SPECIFICATION
|
Model |
HS8AQ |
|
Product Name |
Smart Air Quality Monitor |
|
Working Voltage |
AC220V/50Hz |
|
Display |
LCD |
|
Alarm Indicator |
Buzzer+Three-color LED(Green: Good, Yellow: Moderate, Red: Poor) |
|
Networking |
ZigBee |
|
Detection Method |
Diffusion Type |
|
CO₂ Detection Range |
400 ～ 5000ppm |
|
CO₂ Accuracy |
±(50ppm+5% of Reading) |
|
CO₂ Level |
Good:<1000ppm; Moderate:1000~2000ppm; Poor:≥2000ppm |
|
Temperature Range |
-10°C ～ +50°C |
|
Humidity Range |
0 ～ 95%RH |
|
PM2.5 Detection Range |
1~999μg/m³ |
|
PM2.5 Level |
Good:1~75μg/m³; Moderate:75~150μg/m³; Poor:≥150μg/m³ |
|
Operating Temperature |
-10°C~+55°C |
|
Operating Humidity |
≤95%RH(Non-condensing) |
|
Installation |
Standard 86 Wall Box |
|
Dimensions |
86×86×50mm |
|
Certification |
CE |
SPECIFICATION
| POWER SUPPLYAC 220V/50HZ |
| CO2 RANGE400~5000PPM |
| CO2 ACCURACY100 ppm or 5% of the measured values, Whichever is higher |
| AIR QUALITY/CO2 DENSITYGOOD:<1000PPM NORMAL:1000~2000PPMPOOR:>2000PPM |
| AIR QUALITY/PM2.5 DENSITYEXCELLENT:1~75 UG/M³: GOOD:75~150UG/M³:POOR: >150 UG/M³ |
| PM2.5 DETECTING RANGE1~999MG/M³ |
| OPERATING TEMPERATURE-10°C~55°C |
| OPERATING HUMIDITY≤90%(NO CONDENSATION) |
